stainless steel etc Forland Carbon Steel Q235 2000 Liters 2 Ton Trucks Small Fecal Sewage Suction Truck For Sale

1 Unit
MOQ
stainless steel etc Forland Carbon Steel Q235 2000 Liters 2 Ton Trucks Small Fecal Sewage Suction Truck For Sale
Характеристики Галерея Характер продукции Спросите цитату
Характеристики
Характеристики
Transmission Type: Manual
Condition: New
Emission Standard: Euro 3
Fuel Type: Diesel
Tank Volume: 4500L
车身尺寸: 5995*2050*2200
Horsepower: 95hp
Gross Vehicle Weight: 4400
Drive type: 4x2
Wheelbase: 3200 mm 3360mm 3500mm
Tank material: Q235 Carbon Steel stainless steel etc
Pump: Veyron pump
Chassis brand: Sinotruk ,Shacman, Dongfeng, Foton, FAW, etc.
Certificate: CE. BV. ISO9001. CCC
Warranty: 12 months
Product name: small fecal trucks sewage suction truck
Color: Request Customized
Основная информация
Сертификация: CE. BV. ISO9001. CCC
Оплата и доставка Условия
Packaging Details: 1.small type can ship by container 2.Big size trucks ship by RORO or Bulk ship or flat bed container or open top container 3.Packed according to the clients' requirements small fecal trucks sewage suction truck
Supply Ability: 200 Unit/Units per Month urgent orders can provide overtime production
Характер продукции
Product Description

Small fecal sunction trucks sewage suction truck for sale

Fecal Suction Truck 2 m3 is called Fecal suction vehicle, mainly used in pumping stool,polluted water,sludge,floating debris in all kinds of city's municipal sanitation, agriculture,factory,district,etc.

Features:self-priming, self-discharging, high efficiency.



Basic equipment: inspect fecal window, gravity mouth, cleaning apparatus, fecal suction pipe, oil-water separators, overflow valve Fecal suction gun, special vacuum pump(rating rotate speed=1400r/m, min rotate speed>800r/m, max suction lift>6m, vacuum>500mmHg, steering:clockwise)



Main Features: self-priming, self-discharging, high efficiency,Time for full suction<5min



Tank material optional:carbon steel, stainless steel, epoxy resin anti corrosive processing(in order to contain partial chemical sewage or industrial waste water).



WHAT IS THE SPECIFICATION OF HIGH PRESSURE VACUUM SUCTION VEHICLE?
General Description
Overall Dimension(mm)5995*2050*2200 tanker Dimension(mm)3800*1100*700
Gross weight (kg)4400Driving type4*2,  left hand drive
Curb weight (kg)2705Rated loading capacity kg1500
Wheel  base (mm)3200 mm 3360mm  3500mmAxle number2
Approaching/Departure Angle(°)17/14.5(°)F/R Axle load(kg)1760/2640
Passengers in cab2/3Maximum speed(km/h)95(Km/h)
Number of Tyres6 (1 spare piece)Tyre type7.00-16
Front/Rear suspension(mm)1100/1695(mm)  Front/Rear track base (mm)1506 1466
Transmission5speed forward with 1 reverse, manualFuel typeDiesel oil
Engine parameters
BrandChaochaiModelCY4102-C3F
Displacement (L)3.856 LEmission StandardEURO 3
Maximum power output70KWMaximum horsepower95HP
Number of cylinders4Cylinder spread patternIn-line
Intake typeSupercharged and mid-coolingRated rotation(rpm)3200
Tank body
Tank capacity(L)2000LTank materialQB235 Carbon steel
Product pictures



FAQ

Q1. What is your terms of packing?
A: Generally, our cargo is suitable for naked or waxed packing, in container or bulk ship or RO-RO ship according to the size of the cargo.
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages
before you pay the balance.

Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.

Q4. How about your delivery time?
A: Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.

Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.

Q6. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and
the courier cost.

Q7. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery

Q8: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,
no matter where they come from.

Our Main Products

 We can produce 300kinds of different special vehicals as follow
1. LPG Tank Truck Trailer/ Fuel Tanker Truck
2. Water truck / Water Tank Truck / Water Sprinkler Truck/Water Tanker
3. Truck with crane / Truck mounted crane
4. Dump Truck / Tipper Truck/Side Tipper/End Tipper
5. Fire Fighting Truck / Fire Truck / Fire Vehicle
6. Concrete Mixer Truck
7. Van truck / Blasting equipment transporter/ Refrigerated truck
8. Fecal suction truck / Sewage suction truck,
9. Cement Powder Tank truck/ Bulk cement truck
10. High-altitude operation truck,
11. Self-loading garbage truck, garbage compactor truck,sealed garbage truc
12. Tractor
13. High Pressure Cleaning Truck
14. Sweeper Truck
15. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer

    / low bed trailer / van container trailer / warehouse trailer, etc. )



Packaging&Shipping

Shipping by bulk ship or container or RORO ship or as per your requirement

Big size trucks always shipping by RORO or Bulk ship or flat bed container or open top container , small type can shipping by container

Welcome to contact

The above information is just for your reference. We can manufacture the trucks as per your request and we can fulfill all your demands.Should you have any other questions or need any other information, pls feel free to contact Doreen. It would be my great pleasure to be on your service. Pls check my contact information as following:
